• 12 & 3 O'clock Conduit Entries
• 3-1/2" Shaft Height
• 40°C Ambient
• Stainless Steel Shaft
• Four Thru Bolts on a 5.146 Bolt Circle
• 48/56 Base Mounting
• Sealed Ball Bearings
• UL 1081 Design
• Rigid Base
• Threaded Shaft

Used On:

• TMCP Series 100% Drain Bathtub Pump
• Flo-Master FMHP Series Side Discharge Spa Pump
• Gecko Flo-Master XP/XP2/XP2E 48-Frame
• Jacuzzi LR, LR3, LR6, LR9 Pump Parts
• Jacuzzi Models L Pump Parts
• Gecko Flo-Master FMCP Series Center Discharge Spa Pump
• Jacuzzi K & KM Series Pump Parts

Specifications:

• Phase: 1
• Output HP: 2.0 Hp
• Output KW: 1.5 kW
• Voltage: 230/115 V
• Speed: 3450 rpm
• Service Factor: 1
• Frame: X48Y
• Enclosure: Drip Proof
• Thermal Protection: Thermally Protected
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 10.0/20.0 A
• Duty: Continuous
• Insulation Class: B
• UL: Recognized
• CSA: Y
• Number of Speeds: 1
