• 12 & 3 O'clock Conduit Entries
• 3-1/2" Shaft Height
• 40°C Ambient
• Stainless Steel Shaft
• Four Thru Bolts on a 5.146 Bolt Circle
• 48/56 Base Mounting
• Sealed Ball Bearings
• UL 1081 Design
• Rigid Base
• Threaded Shaft

Used On:

• Aqua-Flo Flo-Master FMCP Pump Parts
• Aqua-Flo Flo-Master FMHP Pump Parts
• Hayward Power-Flo II Pump Parts
• Hayward Power-Flo Matrix Pump Parts
• Jacuzzi B Series Pump Parts
• Jacuzzi L Series Pump Parts
• Jacuzzi LR Series Pump Parts
• Pentair Dynamo Pump Parts
• Pentair Optiflo Pump Parts
• Sta-Rite ABG Series Pump Parts
• Sta-Rite ABG Series Pump with Canopy Parts
• Sta-Rite Delta Pump Parts
• Sta-Rite JW Pump Parts
• Sta-Rite JW Series with Canopy Pump Parts
• Sta-Rite JWP Series Pump Parts
• Waterway Center Discharge Pump Parts

Specifications:

• Phase: 1
• Output HP: 1.5 Hp
• Output KW: 1.1 kW
• Voltage: 230/115 V
• Speed: 3450 rpm
• Service Factor: 1
• Frame: 48Y
• Enclosure: Drip Proof
• Thermal Protection: Thermally Protected
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 8.0/16.0 A
• Duty: Continuous
• Insulation Class: B
• UL: Recognized
• CSA: Y
• Number of Speeds: 1

Unable to sell or install this product in New York or California.
